Buy Waveshare 28730 TOF (time Of Flight) Laser Range Sensor (C), UART / I2C / IO Communication Support, Long Range In India | Fab.to.Lab

This sensor can be widely used in applications like common distance measuring, robot obstacle avoidance / route planning, as well as drone altitude setting / ceiling detection, and more , 0., 02 ~ 7., 8m long range low cost ranging module high stability, high accuracy, high sensitivity ranging It supports UART or I2C communication bus, features longer measuring distance and higher light interference tolerance capability due to its ultra narrow FOV, suitable for either indoor or outdoor condition. Compatible with controller boards like Raspberry Pi/Raspberry Pi Pico/ESP32；Rich WiKi Resources: We provide official Wiki resources, please contact us for more information This sensor can be widely used in applications like common distance measuring, robot obstacle avoidance / route planning, as well as drone altitude setting / ceiling detection, and more   Specifications TYPICAL MEASURING RANGE: 0.02m ~ 7.8mTYPICAL MEASURING ACCURACY: 0.02m ~ 7.8m ± 4cmWAVELENGTH: 940nmFIELD OF VIEW (FOV): 2° ~ 3°COMMUNICATION INTERFACE: Default: UART (3.3V TTL signal level)I2C (cascading support, the slave address is 0x08 + module ID)Complementary I/O level output (distance parameter is not available in this mode)BAUDRATE: UART: 4.8Kbps ~ 3000Kbps (921.6Kbps by default)I2C: up to 400KbpsPOWER SUPPLY: 4.3 ~ 5.2VPOWER CONSUMPTION: 100mW (UART active output, 5.0V power supply, 20mA current)WEIGHT: 1gOPERATING TEMPERATURE: -10°C ~ 60°CDIMENSIONS: 18.8mm × 12mm × 10.3mm (L × W × H)   Cost Effective Solution0.02 ~ 7.8m Long Range Low Cost Ranging ModuleHigh Stability, High Accuracy, High Sensitivity Ranging   UART / I2C / IO Communication SupportUART Mode: Supports Active Query OutputI2C Mode: Up to 8x CascadesI/O Mode: Unable to Output Distance Parameter   Hardware Connections I2C Example: UART Example: I/O Pins Example: Dimensions: Wiki: www.waveshare. Buy Waveshare 28730 TOF (time Of Flight) Laser Range Sensor (C), UART / I2C / IO Communication Support, Long Range In India | Fab.to.Lab TOF10120 I2C and UART Laser Range Finder - Distance Sensor - 10-180cm TOF (Time Of Flight) Laser Range Sensor (B), UART / I2C Bus, Long Range... This ToF (Time of Flight) sensor measures depth and distance by using the time that it takes for photons to travel between two points, from the sensor’s emitter to a target and then back to the sensor’s receiver. It has a measuring range from 0.02 to 7.8 meters with an accuracy of ±4 cm. The sensor uses UART, I/O and I2C communication connections, giving you flexibility with different...
